Energy storage semiconductor dehumidifier – 1000 mL/24h
ADS-1000ML is a compact dehumidifier for battery cabinets, electrical enclosures and energy-storage equipment. Its published removal rating is 1000 mL/24h at 35 °C and 85% RH; final selection should be confirmed against the actual temperature, humidity or dew-point target, moisture load, drainage, power, control and installation conditions.
Product selection should be confirmed against temperature, target humidity, airflow, drainage, power supply, and installation conditions.
Product overview
What ADS-1000ML is designed to do
ADS-1000ML is a compact dehumidifier for battery cabinets, electrical enclosures and energy-storage equipment. Its published removal rating is 1000 mL/24h at 35 °C and 85% RH; final selection should be confirmed against the actual temperature, humidity or dew-point target, moisture load, drainage, power, control and installation conditions.
01
1000 mL/24h rated moisture removal at 35 °C and 85% RH
02
AC 220V and DC 24V configurations under one base model
03
ABS and aluminium-enclosure configurations
04
RS485 communication and external hose drainage
05
Published operating range from -30 °C to +55 °C
Technical data
Product specifications
Values below are retained from the current product record. Final configuration should be confirmed in the project quotation.
Specification
Unit
ADS-1000ML
Dehumidification Capacity (35°C/85% RH)
mL/24h
1000
Power Supply
V
AC 220V / DC 24V
Rated Power
W
150 ABS / 120 aluminium
Rated Current
A
0.7 AC ABS / 6 DC ABS / 0.54 AC aluminium / 5.8 DC aluminium
Airflow
m³/h
75
Communication
—
RS485
Drainage Method
—
External hose drainage
Operating Temperature
°C
-30–+55
Shell Material
—
ABS / aluminium
Installation
—
DIN rail (ABS) / wall screws (aluminium)
Machine Dimensions (L×W×H)
mm
300 × 126 × 85 ABS / 310 × 136 × 72 aluminium
Net Weight
kg
2.75 ABS / 2 AC aluminium / 1.9 DC aluminium
Application fit
Where this product can be evaluated
Application fit depends on the moisture load, operating temperature, room volume, airflow path, and installation constraints.
Confirm the right configuration for your operating conditions.
Share the operating temperature, current and target humidity, room dimensions, airflow, power supply, drainage method, and installation limits. Yakeclimate can use these details to recommend a suitable next step.
